Printing
|
Resolution
|
203dpi
|
|
Printing method
|
Thermal Transfer/Direct Thermal
|
|
Printing speed
|
4-5 Inch/s
|
|
Max printing width
|
104mm (4.09' )
|
|
Max printing Length
|
2286mm (90' )
|
|
Interface
|
USB/ (USB+ Serial+Parallel+Ethernet)
|
|
|
Print head (abrasive resistance)
|
50km
|
|
|
Commands
|
TSC
|
|
Ribbon
|
Ribbon OD
|
Max 60mm
|
|
Ribbon Length
|
Max 300M
|
|
Ribbon width
|
Min. 30mm; Max. 110mm
|
|
Ribbon Core Size
|
25.4mm
|
|
Ribbon Rolling Up Method
|
Outward Rolling
|
Media
|
Max Media Roll OD
|
127mm (5" )
|
|
Min Media Roll ID
|
25mm
|
|
Media Paper Type
|
Continuous, gap, fan hold, black mark,
|
|
Media Rolling Up Method
|
Printing side outward Rolling
|
|
Media width
|
Max 120mm (4.72"), Min: 20mm (0.78")
|
|
Media Roll Core Size
|
25.4mm~38mm
|
|
Media Gap
|
Min.2mm
|
|
Media Thickness
|
0.058mm~0.305mm
|
|
Label Length
|
10mm~2286mm
|
|
Accessories
|
External Media Holder (Optional)
|
|
Software
|
Editing Software
|
Nicelabel SE
|
|
Driver
|
Windows 2000、XP、Vista、Win7、Win8、Windows Server 2003&2008
|
|
Character font
|
Character Set
|
GB18030 (Simplified Chinese)
|
|
Print font
|
ASCII Font A: 12*24
ASCII Font B: 9*24
Chinese: 24*24
|
|
Barcode type
|
1D code
|
Code39, Code93, Code128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-13,EAN-14, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI,PLESSEY, POSTNET, China POS, ITF14
|
|
2D code
|
QR code
|
|
Picture format
|
Graphics processing
|
Support BMP/PCX/BAS
|
Environment
Specification
|
Temperature
|
Working: 5-45°C, Storage: -10~50°C
|
|
Humidity
|
Working : 25%~85% ; Storage: 10%~90%
|
|
Power supply
|
Input: AC 110V/240V, Output: DC24V/2.5A,60W
|
|
Storage
|
4MB
|
|
Dimension
|
223*286*169mm
|
|
Printer weight
|
2.35kg
|
